SST-48
- Tolerance free conical connector system.
- Build for extreme heights and loads
- Steel base equipped with high quality Nylon wheels
- Multi-functional Top Part for use with manual and motorized hoists 4 Side Webbing.
- High stability aluminum alloy.
- High wear resistance.
- 4 mm wall thickness of 60 mm main tube.
The SST-48 Tower is based on 480mm x 480mm vertical beam that allows the safe, quick lifting of regularly loaded horizontal DT Truss to their service height. In terms of static, the SST-48 Tower is designed for a high exural- and pressure strain. It is provided with aluminum (EN-AW-6082-T6).
Top frame and sleeve block. Base is made of steel to provided maximum ground traction needed due to it’s weights and supports. Dual height adjusted on each ground support make it very rigid structure to be used indoor or outdoor.
Technical Specifications
| Height | 480mm |
| Width | 480mm | Main Tube | 60x4mm |
| Sub Tube | 30x3mm |
| Braces | 30x3mm |
| Material | EN-AW-6082 T6 |
| Connection | SG3(60mm) |
Compatibility
