load cell
PROFESSIONAL EVENT SYSTEM
load cell is Giant Truss’s wireless load-monitoring solution for professional rigging and event structures.
- Project-specific platform layouts
- 3D design and engineering support
- Built for professional event workflows
Share your required dimensions, venue details and event date for faster planning.
WHY GIANT TRUSS SYSTEMS
A technical system planned around your project
From the first brief to installation support, Giant Truss helps turn project requirements into a practical, well-coordinated event-system solution.
01
Project-specific layouts
System requirements can be planned around the venue, event format and production workflow.
02
3D design assistance
Detailed layouts help visualise the planned structure and confirm requirements before implementation.
03
Engineering support
Structural reports and static calculations can be supplied with engineering partners where required.
04
Implementation guidance
Support from product planning through to installation guidance for the planned event setup.
GET A FASTER, BETTER QUOTE
Send the key project details with your enquiry
A clear brief helps the Giant Truss team understand the required configuration and respond with a more relevant Giant Truss solution.
Product Overview
load cell is Giant Truss's wireless load-monitoring solution for professional rigging and event structures. It provides real-time measurement, overload alerts and selectable display units, with the published capacity, accuracy, radio range and environmental specifications retained below.
- R.F. : 2.4 GHz range – other ranges available.
- R.F.transmission Range : Up to 450′ /150m in normal operation conditions (outdoors line of sight). Longer transmission ranges are optional.
- Safety Factor : 5:1 Standard. 10:1 and higher safety factors are available.
- Safety features: : Fatigue rated load cells that can withstand successive load cycles for long periods of time without the risk of failure or damage to the steel.
- Proof load : 200%.
- Accuracy Class: 1%
- Capacities: From 0.5t to 12.5t.
- Receivers: USB Desktop Recevier or Bluetooth Portable Receiver
- Functions : Sum, Max, Tare, Zero, Group (LC), Overload detection and alert (visual and audible), Low battery indication, Reports data base, User calibration, Group functions (Sum, Max, Zero, Tare, Overload and customized overload detection), Plan/layout archiving.
- Units : Selectable units feature with the following choice of measurement readings: Tons, Kgs, Lbs.
- Load Cell Material : Made of high-strength, aerospace quality low alloy steel, polyurethane coated.
- Power : 4 x AA 1.5 Volt Alkaline disposable batteries Batteries will function up to 5000 hours (optional 10,000 hours).
- Calibration : User calibration. Initial factory calibration, certified and fully traceable to NIST.
- Temperature Range : Load cell: -15°F to +175°F / -25°C to+80°C.
- Environmental : IP67
