LD 35

⦁ Build for extreme heights and loads
⦁ Up to 10 meters (33ft.)
⦁ Multifunctional Top Part for use with manual and motorized hoists
⦁ Tolerance free
⦁ conical connector
⦁ High stability aluminum alloy
⦁ Excellent load-bearing capacity
⦁ Low dead weight
⦁ High wear resistance
⦁ Extreme strength for extreme circumstances
⦁ Ideal for outdoor or 3-dimensional constructions
⦁ Smart orientation free connection
⦁ Fast and easy to assemble

Request Quote

Description
Additional information

The LD-35 Tower makes for an excellent vertical truss that allows the safe, quick lifting of regularly loaded horizontal JT-H Truss Rig and Roofs to their service height. In terms of static, the LD-35 Tower is designed for a high flexural- and pressure strain.
Especially due to a roof this high, flexural strain is required.

/*! elementor – v3.12.1 – 02-04-2023 */
.elementor-heading-title{padding:0;margin:0;line-height:1}.elementor-widget-heading .elementor-heading-title[class*=elementor-size-]>a{color:inherit;font-size:inherit;line-height:inherit}.elementor-widget-heading .elementor-heading-title.elementor-size-small{font-size:15px}.elementor-widget-heading .elementor-heading-title.elementor-size-medium{font-size:19px}.elementor-widget-heading .elementor-heading-title.elementor-size-large{font-size:29px}.elementor-widget-heading .elementor-heading-title.elementor-size-xl{font-size:39px}.elementor-widget-heading .elementor-heading-title.elementor-size-xxl{font-size:59px}

Technical Specifications

Height	350mm
Width	350mm
Weight	7~6kg/m
Main Tube	50×3(2)mm
Sub Tube	30x2mm
Braces	30x3mm
Material	EN-AW-6082 T6
Connection	SG2

Compatibility
